Incoloy 800 Pipe Fittings

DIN 1.4958 Pipe Fittings, Incoloy Alloy 800 45 / 90 / 180 Degree Elbow, Incoloy 800 Cross, 800HT Incoloy® Alloy Pipe Bend Exporter, JIS NCF 800H Butt weld Fittings, ASME SB366 Alloy 800HT Pipe End Cap, Incoloy N08810 Buttweld Pipe Fittings Manufacturer in Mumbai, India.

Incoloy 800 alloy was modified to Incoloy 800h. This modification was done for controlling the carbon and gain size for optimizing the property such as stress rupture. Furthermore, Incoloy 800ht was modified to the collective level of aluminum and titanium for ensuring to achieve good high-temperature properties. This nickel-based alloy is double certified material. It is combining the properties of forms such as H and HT. Thus Incoloy 800H and Incoloy 800HT are used for the structural applications at the high temperature. The nickel content is making alloy effectively resistant to chloride-ion SSC. In addition to this, it is resistant to embrittlement as of the precipitation phase. Here, in the general corrosion resistance is appreciable.

In the annealed condition, Incoloy 800H and Incoloy 800HT are having remarkable stress rupture and creep-rupture properties. Incoloy 800 is used in the industrial application at temperature to 1100 deg F. Proper chemical balance is allowing it to possess properties like carburization resistance, nitriding atmosphere resistance, and oxidation as well. The testing on Incoloy 800 pipe Fittings is done for checking the strength and working ability. Few tests done on it is like PMI and IGC testing, hardness tests, chemical composition tests, mechanical strength testing. Thus no bad quality of pipe fittings is dispatched.

Incoloy 800/800H/800HT Pipe Fittings Equivalent Grades

STANDARD	WERKSTOFF NR.	UNS	JIS	BS	GOST	AFNOR	EN
Incoloy 800	1.4876	N08800	NCF 800	NA 15	ЭИ670	Z8NC32-21	X10NiCrAlTi32-20
Incoloy 800H	1.4958 / 1.4876	N08810	NCF 800H	NA 15(H)	ЭИ670	Z8NC33-21	X5NiCrAlTi31-20
Incoloy 80HT	1.4859 / 1.4876	N08811	NCF 800HT	NA 15(HT)	ЭИ670	-	X8NiCrAlTi32-21

Incoloy 800/800H/800HT Butt weld Fittings Specification

Specifications : ASTM B366 / ASME SB366

Dimensions : ASME/ANSI B16.9, ASME B16.28, MSS-SP-43

Size : 1/8” NB TO 48” NB. (Seamless & 100% X-Ray Welded, Fabricated)

Type : Seamless / Welded / Fabricated

Bending Radius : R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom

Thickness : Sch 5s, Sch 10s, Sch 40s, Sch 80s, Sch 160s, Sch XXS

Available Types of Incoloy 800/800H/800HT Butt weld Pipe Fittings

Incoloy 800 Elbow

• Incoloy Alloy 800 Elbow
• Alloy 800H Elbow
• JIS NCF 800HT Elbow
• Incoloy 800 90 Deg Elbow
• Nickel Alloy 800H 180° Buttweld Elbow
• Incoloy® Alloy 800HT 45 Degree Elbow
• Incoloy UNS N08811 Pipe Elbow
• Alloy N08800 Pipe Elbow
• DIN 1.4859 Buttweld Elbow
• Incoloy 1.4958 Pipe Elbow
• ANSI B16.9 Alloy 800HT Welded Elbow

Incoloy 800 Tee

• Incoloy Alloy 800 Tee
• Alloy 800H Tee
• JIS NCF 800HT Pipe Tee
• Incoloy 800 Equal Tee
• Nickel Alloy 800H Reducing Tee
• Incoloy® Alloy 800 Unequal Tee
• Incoloy UNS N08800 Buttweld Pipe Tee
• Alloy N08800 Pipe Tee
• DIN 1.4958 Butt weld Tee
• Incoloy 1.4859 Pipe Tee
• ANSI B16.9 Alloy 800HT Pipe Tee

Incoloy 800 Cross

• Incoloy Alloy 800H Cross
• Alloy 800 Cross
• JIS NCF 800HT Pipe Cross
• Incoloy 800 Equal Cross
• Nickel Alloy 800H Reducing Cross
• Incoloy® Alloy 800H Unequal Cross
• Incoloy UNS N08800 Buttweld Pipe Cross
• Alloy N08800 Pipe Cross
• DIN 1.4859 Butt weld Cross
• Incoloy 1.4958 Pipe Cross
• ANSI B16.9 Alloy 800HT Pipe Cross

Incoloy 800 Eccentric Reducer

• Incoloy Alloy 800HT Pipe Eccentric Reducer
• Alloy 800H But weld Eccentric Reducer
• JIS NCF 800 But weld Pipe Eccentric Reducers
• Incoloy 800HT Buttweld Eccentric Reducer
• Nickel Alloy 800H Pipe Eccentric Reducer
• Incoloy® Alloy 800HT Eccentric Reducer
• Incoloy UNS N08810 Eccentric Reducer
• Alloy N08811H Eccentric Reducer
• DIN 1.4859 Eccentric Reducer
• Incoloy 1.4958 Eccentric Reducer
• ANSI B16.9 Alloy 800HT Eccentric Reducer

Incoloy 800 Concentric Reducer

• Incoloy Alloy 800 Pipe Concentric Reducer
• Alloy 800h But weld Concentric Reducer
• JIS NCF 800HT But weld Pipe Concentric Reducers
• Incoloy 800 Buttweld Concentric Reducer
• Nickel Alloy 800H Pipe Concentric Reducer
• Incoloy® Alloy 800H Concentric Reducer
• Incoloy UNS N08811 Concentric Reducer
• Alloy N08800 Concentric Reducer
• DIN 1.4958 Concentric Reducer
• Incoloy 1.4876 Concentric Reducer
• ANSI B16.9 Alloy 800 Concentric Reducer

Incoloy 800 Pipe Cap

• Incoloy Alloy 800H Pipe Cap
• Alloy 800HT But weld End Cap
• JIS NCF 800 But weld End Pipe Cap
• Incoloy 800H Buttweld End Cap
• Nickel Alloy 800HT Pipe Cap
• Incoloy® Alloy 800 End Cap
• Incoloy UNS N08800 Pipe Cap
• Alloy N08810 Pipe Cap
• DIN 1.4876 Pipe Cap
• Incoloy 1.4958 Pipe End Cap
• ANSI B16.9 Alloy 800HT End Pipe Cap

Incoloy 800/800H/800HT Pipe Fittings Chemical Composition and Mechanical properties

• Chemical Composition
• Mechanical properties

Grade	C	Mn	Si	S	Cu	Fe	Ni	Cr
Incoloy 800	0.10 max	1.50 max	1.00 max	0.015 max	0.75 max	39.50 min	30.00 – 35.00	19.00 – 23.00
Incoloy 800H	0.05 – 0.10	1.50 max	1.00 max	0.015 max	0.75 max	39.50 min	30.00 – 35.00	19.00 – 23.00
Incoloy 800HT	0.06 – 0.10	1.50 max	1.00 max	0.015 max	0.75 max	39.50 min	30.00 – 35.00	19.00 – 23.00

Element	Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
Incoloy 800HT	7.94 g/cm3	1385 °C (2525 °F)	Psi – 75,000 , MPa – 520	Psi – 30,000 , MPa – 205	30 %
